MSZ-HZ
Features
Auto Restart
.png)
Dual Barrier Coating (Fan)
Eco Inverter
ElectrostaticAnti-allergyEnzyme Filter
Fast Cooling Mode
Horizontal Vane swing
Long Airflow
Luminous Button
Micro Particle Catching Filter
New IDU design
V-Air Filter
Vane Control Left & Right
Technical Specifications
| Type | Inverter Heat and Cooling | |||||
|---|---|---|---|---|---|---|
| Model name | Indoor unit | MSZ-HZ13VF | MSZ-HZ18VF | MSZ-HZ24VF | ||
| Outdoor unit | MUZ-HZ13VF | MUZ-HZ18VF | MUZ-HZ24VF | |||
| Cooling | Cooling Capacity | Rated (Min-Max) | Watt | 3150 (1400-3500) | 5200 (1700-5600) | 7100 (1800-7100) |
| Power Input | Rated | Watt | 975 (240-1750) | 1540 (300-2210) | 2210 (290-3510) | |
| Air Volume | Indoor unit(SLo-Lo-Med-Hi-SHi) | CFM | 127-162-208-297-459 | 332-360-441-544-639 | 360-441-544-618-696 | |
| Noise Level | Indoor unit(SLo-Lo-Med-Hi-SHi) | dBA | 22-31-37-42-49 | 30-33-38-44-48 | 33-38-44-46-50 | |
| Operating Current | Rated | A | 4.7 | 7 | 10 | |
| Heating | Capacity | Rated (Min-Max) | Watt | 3600 (1100-4100) | 5400 (1400-6500) | 8100 (1500-8500) |
| Power Input | Rated | Watt | 980 (270-1750) | 1260 (250-2210) | 2350 (180-3510) | |
| Air Volume | Indoor unit(SLo-Lo-Med-Hi-SHi) | CFM | 120-155-201-283-459 | 311-371-459-554-639 | 371-459-544-618-696 | |
| Noise Level | Indoor unit(SLo-Lo-Med-Hi-SHi) | dBA | 22-30-36-40-49 | 29-33-38-44-48 | 33-38-44-46-50 | |
| Operating Current | Rated | A | 4.7 | 5.8 | 10.6 | |
| Star Rating | 3 Star | 3 Star | 3 Star | |||
| Energy Efficiency | ISEER | 4.54 | 4.64 | 4.53 | ||
| Refrigerant | R32 | R32 | R32 | |||
| Power supply | Voltage | V | 230V | 230V | 230V | |
| Power Input Range | Voltage | V | 198-264V | 198-264V | 198-264V | |
| Indoor unit | Net Dimensions (H x W x D) | mm | 290x799x232 | 305x923x262 | 305x923x262 | |
| Net Weight | kg | 8.4 | 12.1 | 12.1 | ||
| Outdoor unit | Net Dimensions (H x W x D) | mm | 538x699x249 | 550x800x285 | 714x800x285 | |
| Net Weight | kg | 24 | 35 | 40 | ||
| Pipe Size | Diameter Liquid | mm (inches) | 6.35 (1/4") | 6.35 (1/4") | 6.35 (1/4") | |
| Diameter Gas | mm (inches) | 9.52 (3/8") | 9.52 (3/8") | 12.7 (1/2") | ||
| Additional Refrigerant | gm per meter | 20gm per meter | 20gm per meter | 20gm per meter | ||
| Max.Length | m | 20 | 20 | 30 | ||
| Max.Elevation | m | 12 | 12 | 15 | ||
| Ambient Operating Range | Cool | °C | 21°-46° | 21°-46° | 21°-46° | |
| Heat | °C | -10°-24° | -10°-24° | -10°-24° | ||
| Control wiring (Copper) | ODU to IDU | Core No. x Sq.mm | 4 Core x 1sq.mm | 4 Core x 1sq.mm | 4 Core x 1sq.mm | |
| Power cable (Copper) | ODU | Core No. x Sq.mm | 3 Core x 1sq.mm | 3 Core x 1sq.mm | 3 Core x 2sq.mm | |
| ODU Breaker Size | A | 10 | 10 | 16 | ||
| MRP | 59500 | 77300 | 99600 | |||
