MSY-GZ
Features
Auto Restart
.png)
Blue Fin for Outdoor Condenser (Corrosion toughness)
Error Code display on Remote Controller
Fast Cooling Mode
Heat Caulking Fixing Method
Horizontal Vane swing
Long Airflow
Luminous Button
Micro Particle Catching Filter
Reluctant DC Rotary Compressor
Single Coating
Sleep Mode
Technical Specifications
| Type | Inverter Cooling only | |||||
|---|---|---|---|---|---|---|
| Model name | Indoor unit | MSY-GZ13VF | MSY-GZ18VF | MSY-GZ22VF | MSY-GZ26VF | |
| Outdoor unit | MUY-GZ13VF | MUY-GZ18VF | MUY-GZ22VF | MUY-GZ26VF | ||
| Cooling Capacity | Rated (Min-Max) | Watt | 3350 (1400-4500) | 5200 (1800-6000) | 6600 (1800-7200) | 7600 (2100-9200) |
| Star Rating | 5 Star | 5 Star | 4 Star | 4 Star | ||
| Energy Efficiency | ISEER | 5.61 | 5.6 | 5 | 5 | |
| Power Input | Rated (Min-Max) | Watt | 760 (320-2180) | 1140(320-2350) | 1670 (320-2650) | 1900 (430-3780) |
| Air Volume | Indoor unit(SLo-Lo-Med-Hi-SHi) | CFM | 121-150-203-271-441 | 290-364-427-505-687 | 323-375-440-538-710 | 314-413-498-576-721 |
| Noise Level | Indoor unit(SLo-Lo-Med-Hi-SHi) | dBA | 19-24-31-38-48 | 27-33-38-44-49 | 28-36-41-45-51 | 30-37-42-46-53 |
| Refrigerant | R32 | R32 | R32 | R32 | ||
| Power supply | Voltage | V | 230V | 230V | 230V | 230V |
| Power Input Range | Voltage | V | 160-264V | 160-264V | 160-264V | 160-264V |
| Operating Current | Rated (Min-Max) | A | 3.6 (1.9-9.5) | 5.1 (1.8-10.2) | 7.6 (1.8-11.5) | 8.4 (2.0-16.4) |
| Indoor unit | Net Dimensions (H x W x D) | mm | 280x838x234 | 325x1100x261 | 325x1100x261 | 325x1100x261 |
| Net Weight | kg | 9.8 | 16 | 16 | 16 | |
| Outdoor unit | Net Dimensions (H x W x D) | mm | 545x780x294 | 714x800x285 | 714x800x285 | 880x840x330 |
| Net Weight | kg | 28 | 37 | 37 | 51 | |
| Pipe Size | Diameter Liquid | mm (inches) | 6.35 (1/4") | 6.35 (1/4") | 6.35 (1/4") | 6.35 (1/4") |
| Diameter Gas | mm (inches) | 12.7 (1/2") | 12.7 (1/2") | 12.7 (1/2") | 15.88 (5/8") | |
| Additional Refrigerant | gm per meter | 10gm per meter | 10gm per meter | 10gm per meter | 10gm per meter | |
| Max.Length | m | 20 | 20 | 20 | 30 | |
| Max.Elevation | m | 12 | 12 | 12 | 15 | |
| Ambient Operating Range | °C | 21°-52° | 21°-52° | 21°-52° | 21°-52° | |
| Control wiring (Copper) | ODU to IDU | Core No. x Sq.mm | 4 Core x 1Sq.mm | 4 Core x 1Sq.mm | 4 Core x 1Sq.mm | 4 Core x 1Sq.mm |
| Power cable (Copper) | ODU | Core No. x Sq.mm | 3 Core x 1sq.mm | 3 Core x 1sq.mm | 3 Core x 2sq.mm | 3 Core x 2.5sq.mm |
| ODU Breaker Size | A | 10 | 10 | 16 | 20 | |
| MRP | 58550 | 73000 | 83100 | 106500 | ||
